Designed for customers who want a no-frills 4x4 SUV or for those looking to customise their very own vehicle for rugged off-road adventure
STANDARD
OPTIONAL
For customers looking for off-road capability with greater comfort, technology and convenience
STANDARD
includes Base content plus:
OPTIONAL
Next-level outdoor adventure adds heavy-duty off-road hardware and marine-grade washout interior
STANDARD
includes Big Bend™ content plus:
OPTIONAL
For customers who prefer style and technology on-road and off
STANDARD
includes Big Bend content plus:
OPTIONAL
The all-out desert runner, Bronco Wildtrak comes with the Sasquatch™ Package, 35-inch tires and seven G.O.A.T. Modes including Baja
STANDARD
includes Outer Banks™ content plus:
OPTIONAL
Designed for the ultimate in Bronco 4x4 off-road capability, Bronco Badlands comes with its own unique heavy-duty suspension that includes a front stabiliser bar disconnect
STANDARD
includes Big Bend content plus:
OPTIONAL
VEHICLE TYPE
Front-engine, midsize 4x4 SUV on fully boxed, high-strength steel frame with removable doors, roof sections and body panels; four-passenger two-door, five-passenger four-door models available
STANDARD ENGINE
2.3-liter turbocharged direct injection DOHC Ti-VCT EcoBoost® I4; projected 270 horsepower, 310 lb.-ft. torque
OPTIONAL ENGINE
2.7-liter twin-turbocharged port and direct injection DOHC Ti-VCT EcoBoost® V6; projected 310 horsepower, 400 lb.-ft. torque
TRANSMISSION
Gear Ratios | |||
Standard: 7-speed (6+1 crawler gear) Getrag manual (offered on 2.3L engine only) |
Optional: 10-Speed automatic (available on both 2.3L and 2.7L engines) |
||
Crawler | 6.588:1 | ||
1st | 4.283:1 | 1st | 4.714:1 |
2nd | 2.365:1 | 2nd | 2.997:1 |
3rd | 1.453:1 | 3rd | 2.194:1 |
4th | 1.000:1 | 4th | 1.769:1 |
5th | 0.776:1 | 5th | 1.521:1 |
6th | 0.646:1 | 6th | 1.275:1 |
Reverse | -5.625:1 | 7th | 1.000:1 |
8th | 0.853:1 | ||
9th | 0.689:1 | ||
10th | 0.636:1 | ||
Reverse | -0.4885:1 |
TRANSFER CASE
Standard: 4x4 with part-time selectable engagement – two-speed electronic shift-on-the-fly 2.72:1 low ratio
Optional: Advanced 4x4 with automatic on-demand 4H engagement – two-speed electromechanical transfer case 3.06:1 low ratio
CRAWL RATIO**
Automatic with electronic shift-on-the-fly: 57.19:1
Automatic with electromechanical transfer case: 67.8:1
Manual with electronic shift-on-the-fly: 79.92:1
Manual with electromechanical transfer case: 94.75:1
**Maximum ratios with high-capability option packages
DIFFERENTIAL
Rear Axle: Dana 44™ AdvanTEK® solid rear axle with available Spicer® Performa-TraK™ electronic locking differentials
Front Axle: Dana AdvanTEK independent front differential unit with available Spicer® Performa-TraK electronic locking differentials
Available Final Drive Ratios | |||
Manual | Auto | Sasquatch | |
Base™ | 4.46:1 | 3.73:1 | 4.70:1 |
Big Bend™ | 4.46:1 | 3.73:1 / 4.27:1 | 4.70:1 |
Black Diamond™ | 4.46:1 | 4.46:1 | 4.70:1 |
Outer Banks™ | N/A | 3.73:1 / 4.27:1 | 4.70:1 |
Wildtrack™ | N/A | N/A | 4.70:1 |
Badlands™ | 4.70:1 | 4.46:1 | 4.70:1 |
CHASSIS
Front: Independent H.O.S.S. (High-Performance, Off-Road, Stability, Suspension) System with twin alloy A-arms and coil-over springs for optimum off-road stability and control with available H.O.S.S. System with Bilstein® Position Sensitive Dampers.
Rear: Solid five-link rear axle H.O.S.S. (High-Performance, Off-Road, Stability, Suspension) System with coil-over springs for optimum off-road capability and durability with available H.O.S.S. System with Bilstein Position Sensitive Dampers.
Off-road capability | Two-door | Four-door |
Ground Clearance | 213mm (Base) / 295mm (35" tyres) | 211mm (Base) / 292mm (35" tyres) |
Suspension travel (F/R) | 200mm / 215mm (Base) 240mm / 162mm (Badlands) |
200mm / 215mm (Base) 240mm / 162mm (Badlands) |
Approach angle (deg) | 35.5 (Base) / 43.2 (35" tyres) | 35.5 (Base) / 43.2 (35" tyres) |
Breakover angle (deg) | 21.1 (Base) / 29.0 (35" tyres) | 20.0 (Base) / 26.3 (35" tyres) |
Departure angle (deg) | 29.8 (Base) / 37.2 (35" tyres) | 29.7 (Base) / 37.0 (35" tyres) |
Ramp travel index (Badlands only) (Sta-bar connected & disconnected) |
560 / 700 (projected) | 500 / 620 (projected) |
Maximum water fording | 851mm | 851mm |
WHEELS | Series | |
Standard | Base | 16" bright polished silver-painted steel |
Standard | Big Bend | 17" Carbonized Gray-painted aluminium |
Standard | Black Diamond | 17" black gloss-painted black steel |
Optional | Black Diamond | 17" black high-gloss-painted aluminium |
Standard | Outer Banks | 18" bright machined black high-gloss-painted aluminium |
Standard | Badlands | 17" Carbonized Gray-painted aluminium |
Optional | Badlands | 17" black high-gloss-painted forged aluminium carbonized beauty ring, beadlock-capable |
Standard | Wildtrak | 17" black high-gloss-painted forged aluminium carbonized beauty ring, beadlock-capable |
Sasquatch Package | ||
Standard | Big Bend, Black Diamond, Badlands | 17" black high-gloss-painted forged aluminium carbonized beauty ring, beadlock-capable |
(included in Sasquatch Package on Wildtrak) | ||
Optional | Big Bend, Black Diamond, Badlands | 17" black high-gloss-painted forged aluminium carbonized beauty ring, beadlock-capable |
TYRES (all dimensions measured in inches) |
|||||||
Size (diameter) Size (width) |
30 255/70R16 |
32 255/75R17 |
32 255/70R18 |
32 265/70R17 |
33 285/70R17 |
33 285/70R17 |
35 315/70R17 |
Wheel size | 16x7 | 17x7.5 | 18x7.5 | 17x7.5 | 17x8 | 17x8 | 17x8.5 |
Tread Type | A/S | A/T | A/T | A/T | A/T | M/T | M/T |
Supplier | Bridgestone | Bridgestone | Bridgestone | Generl Tire | BF Goodrich | Goodyear | Goodyear |
Brand | Dueler H/T 685 | Dueler A/T RH-S | Dueler A/T RH-S | General Grabber A/Tx | All-Terrain TA KO2 | Territory | Territory |
Series | Base | Big Bend | Outer Banks | Black Diamond | Badlands | Badlands (optional) | Sasquatch Wildtrak |
Two-door | Four-door | |
Wheelbase | ||
Base | 2550mm | 2949mm |
Big Bend | 2550mm | 2949mm |
Wildtrak | 2550mm | 2949mm |
Badlands | 2550mm | 2949mm |
Length | ||
Base | 4412mm | 4811mm |
Big Bend | 4412mm | 4811mm |
Wildtrak | 4412mm | 4811mm |
Badlands | 4440mm | 4839mm |
Height | ||
Base | 1826mm | 1854mm (soft top) |
Big Bend | 1852mm | 1852mm |
Wildtrak | 1910mm | 1913mm |
Badlands (when available roof racks are installed, add 91mm to two-door models, 86mm to four-door models for max height) |
1875mm | 1877mm |
Width (with mirrors folded) | ||
Base/Big Bend | 1928mm | 1928mm |
Wildtrak | 2014mm | 2014mm |
Badlands | 1938mm | 1938mm |
Track width (front/rear) | ||
Base/Big Bend/Badlands | 1651mm/1651mm | 1651mm/1651mm |
Wildtrak | 1699mm/1699mm | 1699mm/1699mm |
Towing/Payload | ||
Max. available tow | 1587kg | 1587kg |
Max. payload | 531kg | 531kg |
Dynamic roof load | 50kg | 50kg |
Static roof load | 204kg | 204kg (where offered, not available on four-door model with 315/70R17 tyres) |
